Titan AV 3m CAT5e Snake Loom

Titan AV's 3m Cat5E snake loom Features a Mini-4 style stage box that's wired with Cat5E cable that terminates in 4 Ethercon connectors. To top it off, you'll have a much easier time keeping track of which channel is which, since each one is individually colour coded so you'll always know which cable leads where.

Designed to link 16 channels of 3 pin XLR Audio, AES & DMX via Ethernet Cat5e or Cat6 cable. Common applications are for use in stage production, studio and live band, the loom/snake will help speed up setup and pull down as well eliminate cable mess. With quality shielded cables and quality connectors you can rest assured this multi network etherCON CAT SNAKE will eliminate any interference whilst transferring high quality analogue or digital signals.

Titan AV Audio connectors and adapters are ergonomic, high quality, reliable and backed up with a limited lifetime warranty.

*Please note this product does not work with 48v phantom power unless using true shielded cable

Features:

• 16 XLR analogue/digital signals down a shielded CAT loom
• EtherCON connection RJ45
• RJ45 jack CAT6 or CAT5e shielded cable
• High quality custom connectors and cable
• Gold plated connectors
• Perfect for use with balanced Audio, DMX & AES/EBU signals
• Multi-banded oxygen-free copper conductor
• PE insulation which provides a low capacitance dielectric
• Conductive PVC helps to reinforce shielding
• Helical shield resists electromagnetic interference
• Free from micro-phonics
• Durable flexible matte black outer PVC jacket keeps the cable abrasion-resistant
• 100% Screening
• Warranty: Limited lifetime warranty

Specs:

• Length: 3m (Total length including jacks & etherCON hub)
• Colour: Black
• 54cm Fantail extension cord (each connector)
• Balanced analogue audio up to 50m
• AES/EBU/DMX signal up to 100m
• DMX matching impedance: 110 Ohm
• Transmits 16 channels of balanced analogue signal
• Transmits 16 channels of AES signal (eight audio channels)
• 1 x Multi Network etherCON Cat5e Snake
